Cement Screw Feeder
Key Specifications / Features
Model No.: C-02 Hits: 47
Cement screw feeder supplier in China provides customized cement screw feeder for unloading and feeding powdery materials, small-size, smooth, steady.
Request a quote
Share
Tags:
Detail Infomation
Screw feeder is a kind of mechanism to create steady feeding flow and delivery which is suitable for the continuous and homogeneous feeding of dry powdery materials such as raw materials, coal, cement and other powdery material. Commonly used in powdery material silo unloading and feeding materials at the bottom silo bottom.
SINOSAPRE offers the following types of Screw Feeder for different choices:
Single Screw Feeder
Single screw feeder with no jamming inlet which can guarantee high feeding rate, the feeder outlet has a special shape blade to mix materials and with easy feed ability. The single screw feeder has several types divided by speed control methods, fixed rotational speed, manual speed regulation.
SINOSAPRE offers the following types of Screw Feeder for different choices:
Single Screw Feeder
Single screw feeder with no jamming inlet which can guarantee high feeding rate, the feeder outlet has a special shape blade to mix materials and with easy feed ability. The single screw feeder has several types divided by speed control methods, fixed rotational speed, manual speed regulation.
| Single Screw Feeder Technical Parameters | ||||||
| D(MM) | Φ100 | Φ200 | Φ250 | Φ300 | Φ350 | |
| L | mm | 800 | 1200 | 1200 | 1500 | 1500 |
| S | mm | 80 | 175 | 200 | 240 | 240 |
| S1 | mm | 70 | 150 | 180 | 226 | 200 |
| Feeding Capability | m3/h | 0.18-0.6 | 1.8-9 | 3.6-18 | 9-45 | 13-65 |
| Cycloidal Gear Reducer | Type | BWT12-29 | BWT18-29 | BWT18-23 | BWT22-23 | BWT22-17 |
| Power | 0.55 | 1.5 | 2.2 | 4 | 7.5 | |
| Speed Ratio | 29 | 29 | 23 | 23 | 17 | |
| Speed of Outlet Shaft | 4.5-42 | 4.5-42 | 5.5-54 | 5.5-54 | 8-73 | |
| Adjustable-Speed Motor | Type | YCT112-4A | YCT132-4B | YCT160-4A | YCT180-4A | YCT200-4B |
| Power | 0.55 | 1.5 | 2.2 | 4 | 7.5 | |
Twin Screw Conveyor
Twin screw conveyor equipped with cycloidal gear reducer and suitable for dry powdery material (like ash, cement, grain, sand, etc.) continuous and homogeneous feed.
| Twin Screw FeederTechnical Parameters | |||||
| Type | Rotate Speed（r/min） | Delivery Capability（m3/h） | Power for Calculation (kw) | Speed Reducer | Weight /Kg |
| Φ125×1500 | 20～80 | 2～5 | 0.491 | BWD18-17-2.2 | 1160 |
| Φ125×2500 | 20～80 | 2～5 | 0.871 | BWD18-17-2.2 | 1340 |
| Φ150×1500 | 26～79 | 5～10 | 0.987 | BWD18-17-2.2 | 1550 |
| Φ150×2500 | 26～79 | 5～10 | 1.635 | BWD22-17-4.0 | 1750 |
| Φ175×1500 | 25～80 | 6～16 | 1.57 | BWD22-17-4.0 | 1750 |
| Φ175×2500 | 25～80 | 6～16 | 2.62 | BWD22-17-4.0 | 1850 |
| Φ200×1500 | 25～80 | 8～25 | 2.45 | BWD22-17-4.0 | 1820 |
| Φ200×2500 | 25～80 | 8～25 | 4.09 | BWD22-17-5.5 | 1980 |
| Φ250×2500 | 20～65 | 11～34 | 5.55 | BWD22-17-7.5 | 2450 |
| Φ300×3000 | 20～65 | 20～65 | 12.5 | BWD33-17-15 | 3050 |
FEATURES & BENEFITS
1. Wide Speed Range
2. Smooth Operation
3. Low Noise
4. Compact Structure
5. Size Small
6. Steady Material Flow
7. Highly Suitable
8. Customized
APPLICATIONS
Bulk material feeding and conveying.
